Steel Coil Slitting Machine China Famous Brand Slitting Machine Manufacturer

FOB Reference Price:Get Latest Price
$100,000.00 - $500,000.00 / Sets | 1 Set/Sets whole line (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Model Number:
SL
Place of Origin:
Jiangsu, China
Brand Name:
LX
Suitable material:
CR, HR, stainless steel, galvanized steel, etc
Thickness:
depends on users
Width:
depends on users
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
10 Set/Sets per Quarter lines
Packaging & Delivery
Packaging Details
seaworthy nude packing, using steel wire and wood bock to fix the machine inside container, and using the film cover the machine for dustproof
Port
Shanghai
Lead Time :
about 90-120 days after receipt of prepayment

Product Description



Steel Coil Slitting Line
Uncoiler, feeder, slitter, tensioning and recoiler production line


Description
This slitting line is used for slitting raw material coils into strips. This machine can slit raw material coils into specific width. Our company has series of slitting lines, with thickness of 0.1-25mm and width up to 2500mm. The slitting line normally includes loading trolley, decoiler,guiding device (including lead roll, peleer table), coil head shear, centering and calibrating device, slitting machine, scrap rewinder, pre-distribution and tensioning machine, recoiler, and unloading trolley. The machine adopts PLC VF controlling system, DC driving for the slitting and recoiling, Touch screen operating and digital display. The production line is widely used for steel coil servcing for cold rolled steel, hot rolled steel, galvanized steel, stainless steel, etc.





Feature of the Machine

1. Double cone heavy duty decoiler, capacity up to 20, 30, 40 tons(as per need)

2. DC or AC driving for slitting and recoiling

3. Mitsubishi PLC controlling, VF speed control, touch screen operating

4. High speed design depends on material thickness

5. China famous brand products, specialized in the manufacturing slitting line and cut to length line





Work Flow

Material loading -- Uncoiling -- sheet feeding --  sheet head cutting -- center adjusting -- slitting -- tensioning and separating -- recoiling -- product unloading





Main Machine Components

Coil car.......................................................................................................1 set

Decoiler……...............................................................................................1 set

Feeding device..............……..……………...................................................1 set

Center adjusting device………………………..………………………………..1 set

Slittingng machine…..…………….………………………………………….…..1 set

Tensioning and pre-separater………..…………………………………………1 set

Recoiler.......................................................................................................1 set

Unloading coil car........................................................................................1 set

Hydraulic station………………..………………………………………………....1 set

Pneumatic system………………………………………………………………...1 set

Electric control system………….……….......................................................1 set











Main Electric Elements

Motor controller: Eurotherm/ Siemens/Mitsubishi

PLC: Mitsubishi/Siemens

Encoder: Omron

Inverter: Mitsubishi/Yaskawa/Delta

Touch screen: Inovance/Delta



Parameters:
1. Precision high speed slitting line:

seriesmaterial thickness/mmMaterial widthspeed/mpm
10.2-3400-20000-250

2. Series of slitting lines:

seriesmaterial thickness/mmMaterial widthspeed/mpm
10.2-2400-20000-50-150
20.3-3400-20000-50-120
30.5-4500-25000-50-120
40.8-6500-25000-50-100
52.0-8500-25000-50-80
62.0-10500-25000-30-50
73.0-12800-25000-30-50
83.0-14800-25000-30-50
94.0-16800-25000-30-50
105.0-20800-25000-30




Packaging & Shipping

According to the line spec, FCL will be needed for the shipment.

Normally three or more 40 feet containers for shipment


Our Services
  • One stop service for customized machine
  • Overseas installation & operating training
  • One year warranty of the whole machine
  • Life-long technical support

FAQ

1. Machine installation & commissioning, training:

1-2 technicians will be dispatched to Buyer’s plant for installation & commissioning. Work period: in 5 days

The expense of round trip tickets, accommodation, safety and interpretation shall be covered by Buyer, additional pay allowance to the technicians.

2. warranty: one year

3. Price basis: FOB or CNF or CIF

4. We will provide the foundation drawing to Buyer in 20 days after receiving the down payment.



Foundation Reference
