China Famous Brand Steel Coil Leveling and Cutting to length Machine

FOB Reference Price:Get Latest Price
$60,000.00 - $500,000.00 / Sets | 1 Set/Sets whole line (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
LX
Model Number:
Cut to Length line
DC controller:
Eurotherm, British
Width:
<=2500mm
Electric elements:
Chint, China famous brand
Color:
main in green, dangerous area in yellow, or as per your demand
Thickness:
0.2-3mmm, 1-6mm, 2-8mm, 4-16mm, 8-25mm
Air cylinders:
Wuxi Jianeng, China famous brand
Safety standard:
IP40
Bearings:
Harbin, China famous brand
Hydraulic elements:
Beijing Hydraulic Elements Factory, China famous brand
PLC:
Mitsubishi
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
10 Set/Sets per Quarter lines
Packaging & Delivery
Packaging Details
seaworthy nude packing,
approx three containers are needed for shipment.,
using steel wire and wooden to fix the machines inside the container
Port
Shanghai
Lead Time :
about 120-150 days after recepit down payment

Product Description

Cut to Length Line

Steel coil leveling and cutting line



We offer professional one-stop service for the production line

The thickness is up to 25mm, the max. width is 2500mm

We design and produce the machine according to client's requirements.





Description
This Cut to Length Line is suitable for decoiling, leveling & cutting steel coils into required length. The production line has the feature of high precision, topping stabilization, and excellent performance. Using PLC system to control the whole line’s work, the operation is convenient and easy.

The machine adopts PLC VF controlling system, DC driving for the leveling, Touch screen operating and digital display. The production line is widely used for steel coil servcing for cold rolled steel, hot rolled steel, galvanized steel, stainless steel, etc.





Feature of the Machine

1. Double cone heavy duty decoiler, capacity up to 40 tons(as per need)

2. DC or AC driving for levelling

3. Mitsubishi PLC controlling, VF speed control, touch screen operating

4. High speed design depends on material thickness

5. China famous brand products, specialized in the manufacturing slitting line and cut to length line





Work Flow

Feeding trolley→ un-coiler→ leading and traction head, pinch roll feeding→ high precision leveling device→ cut to length→ unloading table/auto-stacking table




Main Machine Components

Feeding trolley………………………………………………………………..…..........1 set
Hydraulic dual cone decoiler…………………………………………….….....…......1 set
Guiding device…………………..…..……....………………………………......….….1 set
Feeder…..............……...…………………………………………………..................1 set
Calibrating and centering unit…..………………………………………….....…....…1 set
4-Hi Precision leveler…....………………..…………………………………...…........1 set
Shear..............…………………………………………………………..….….......…...1 set
Auto- stacker………….……….………………………………………………..…........1 set
Hydraulic station……………………..................................................................…1 set
Electric control system………………..……….……………………………........…....1 set



Main Electric Elements

Motor controller: Eurotherm/ Siemens/Mitsubishi

PLC: Mitsubishi/Siemens

Encoder: Omron

Inverter: Mitsubishi/Yaskawa/Delta

Touch screen: Inovance/Delta





Spec list of Cut to length line










Packaging & Shipping

According to the line spec, FCL will be needed for the shipment.

Normally three or more 40 feet containers for shipment




Our Services



  • One stop service for customized machine
  • Overseas installation & operating training
  • One year warranty of the whole machine
  • Life-long technical support

FAQ



1. Machine installation & commissioning, training:

2-3 technicians will be dispatched to Buyer’s plant for installation & commissioning. Work period: in 30 days

The expense of round trip tickets, accommodation, safety and interpretation shall be covered by Buyer, additional pay allowance to the technicians.

2. warranty: one year

3. Price basis: FOB or CNF or CIF



Foundation reference
