High quality Kerosene vapor phase drying equipment, machine for transformer

FOB Reference Price:Get Latest Price
$100,000.00 - $500,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Model Number:
kerosene vapor phase dryin equipment
Condition:
New
Type:
Vacuum Drying Equipment
Place of Origin:
Jiangsu, China
Brand Name:
Haoshuo
Voltage:
380V
Power(W):
depends on oven size
Dimension(L*W*H):
7000 x 4500 x 4500mm~16000 x 6000 x 7000mm (as required)
Weight:
3-50 Tons Depend
Certification:
CE ISO
Max. working temperature:
135 ± 5°C
Temperature controlling precision:
± 5°C
Ultimate vacuity:
≤ 20Pa (non-load)
Heating Medium:
kerosene
Application:
transformer industry
Control:
Full-automatic
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 Year
Supply Ability
Supply Ability:
30 Set/Sets per Year
Packaging & Delivery
Packaging Details
This kind of machine should adopt nude packaging and sea shipping by container.
Port
Shanghai
Lead Time :
Shipped in 90 days after advance payment
Product Description

High quality Kerosene vapor phase drying equipment, machine for transformer

Product Application

Kerosene vapor phase drying equipment (KVPD) is mainly used for drying bodies for 110KV and more super high voltage transformer and reactors, etc. The basic principle is that: liquid kerosene is evaporated by heating. High temperature kerosene vapor go into the vacuum tank and attach the workpiece, it will condense and release latent heat of condensation (about 306.6KJ/KG), and the workpiece will be heated. Condensed kerosene will be collected and transmitted to the evaporator to be heat again. In this way, workpiece will be heated continuously to evaporate the water. Water vapor shall be exhausted under vacuum condition. In the end workpiece shall be complete dried.

Process Features:

1.Kerosene vapor as heating media which can convective heat and release heat by condensing. The condensing will be more acute at lower temperature, so the workpiece temperature can be uniform
2.After condensing the liquid kerosene will cover the surface of workpiece and exchange heat. So the heat efficiency is much high
3.Due to saturation pressure of kerosene is far less than that of water but higher than transformer oil, kerosene can be evaporated quickly without effecting diffusion coefficient of water at high vacuum condition
4.Heating is under vacuum without oxygen so the insulation materials will not be aged. At the same time the partial pressure of water vapor will be increased to 98000Pa, so the water evaporation will be faster
5.Condensed kerosene is easily infiltrated into the workpiece to accelerate the thermal conductivity and to make deep temperature uniform
6.Kerosene is a very good cleaning solvent. It can clean the workpiece. This is the special feature of KVPD. So KVPD is very suitable for transformer repairing.

High quality Kerosene vapor phase drying equipment, machine for transformer
Vacuum tank
1 set
Trolley and driving device
1 set
Vacuum pump system
1 set
Low temperature condensate system
1 set
Kerosene evaporation system
1 set
Kerosene storage and conveyer system
1 set
Heating system
1 set
Pneumatic pipeline system
1 set
Cooling water system
1 set
Hydraulic system
1 set
Ventilation system
1 set
Control system
1 set
Quality Control

1. We strictly control the quality of raw materials and we can offer inspection certificate of our raw materials for you.
2. We do manufacturing strictly according to the technological processes. Besides, we carry out sampling inspection for our products.
3. All of our workers have received relevant quality management training so that the quality of products can be ensured.
Our goal is to offer the best solution for our customers, supply high quality machine and good service with reasonable price. We sincerely hope to cooperate with worldwide customers for mutual success.

FAQ

1) Q: Are you manufacturer or trading company?
A: We are manufacturer and trading company .

2) Q: Do you provide installing and training overseas?
A: Overseas machine install and worker training services are optional.

3) Q: How is your after sales support?
A: We provide technical support on line as well as overseas services by skillful technicians.

4) Q: How does your factory do regarding quality control?
A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment.

5) How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) We welcome your visit us and test machine by yourself in our factory.

6) Q: Do you sell only standard machines?
A: No. Most machines are made to order.

7) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. We are Gold supplier of Alibaba with SGS assessment (Audit report can be provided).
