VPI Transformer Motor Vacuum Pressure Impregnation Equipment System

FOB Reference Price:Get Latest Price
$50,000.00 - $150,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
DN1200*6000
Customization:
size (Min. Order: 1 Sets)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
Haoshuo, Haoshuo
Condition:
New
After-sales Service Provided:
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Engineers available to service machinery overseas
operation ways:
automatic operation
Capacity:
200-2000kg/h
alarm ways:
over pressure and finished alarm
pressure:
1.58Mpa
temperature:
20-120 degree
tightness:
silica fill air seam
Material:
Stainless Steel
Color:
red
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
This kind of machine should adopt nude packaging and sea shipping by container.
Port
Shanghai
Product Description

This kind of equipment is mainly application of insulation processing for electrical products, such as high voltage motor, generator, H class dry type transformer, power capacitor, cable insulation, and motor repairing, etc. For example, coil windings of motor or transformer can be evaporated at vacuum condition to reduce influence from moisture, air or other impurities. With pressure impregnation, resin can be immersed into inner side to make the high insulation class. VPI equipment is also used in material industry for improving material performance.


Looking for any transformer machine please feel free to get a quotation from us!

Technology Advantage


1. Easily evaporate moisture and air
2. Residual water rate less than 10ppm, good insulation performance
3. Good humidity resistance
4. High dielectric property
5. Resin materials recycle use
6. High efficiency with good quality

Technology Data
Model
Capacity(M3_
Treat capacity
Working pressure
Vacuum degree
DN1200*4000
4.6
3.0
1.0-1.58Mpa ,

special design
-0.098Mpa
DN1200*6000
6.9
4.0
DN1200*8000
9.1
5.2
DN1500*4000
1.7
4.0
DN1500*6000
11
6.0
DN1500*8000
14
8.5
DN1700*4000
9.2
5.2
DN1700*8000
18.3
11
DN1800*4000
10.3
5.8
DN1800*6000
15.5
9.0
DN1800*8000
20.5
12
DN2000*6000
19
11
DN2000*8000
26
14
DN2000*10000
33
22
DN2000*12000
37.68
25.12
DN2000*14000
43.96
29.3
Dn2000*18000
55
32
